This electric plate compactor has a small frame to work in confined areas. Operators can add separate accessories to handle brick paving and asphalt surfacing work on site.
Products Advantages
Built-in transport wheels make moving the machine around job sites simple, no extra lifting work needed. Its narrow frame reaches tight trenches, foundation edges and wall gaps where large compactors cannot get in.
It compacts sand, gravel and mixed standard backfill soils well. Fit the optional rubber mat when compacting brick surfaces to stop scratches. Add a water sprinkler system for hot or cold asphalt work to keep asphalt from sticking to the plate.
One single machine works for most small compaction jobs, so buyers do not need multiple separate compactors for different projects.
Application
Work for trench backfilling, foundation compaction, and tamping along walls and bridge abutments. It also works on new highway sections, street resurfacing and bridge deck laying for municipal and road construction projects.
Technical Parameters
|
GASOLINE PLATE COMPACTOR ZBR75 |
|
|
WEIGHT |
75KG |
|
EXCITING FORCE |
13KN |
|
DIMENSION |
700*400*910MM |
|
DIMENSION OF TAMPING PLATE |
560*400MM |
|
VINRATION FREQUENCY |
43RPM |
|
OPERATION SPEED |
14-18M/MIN |
|
ENGINE MODEL |
HONDA GX160/KOHLER CH260 |
|
HORSE POWER |
6HP |
|
WATER TANK VOLUME |
7.5L |
|
CERTIFICATION |
2006/42/EC - 2006/95/EC / ISO 9001:2008 |
