Vibrating Compactor Plate

Vibrating Compactor Plate

Workers cut physical strain during soil and asphalt compaction with this Vibrating Compactor Plate fitted with Honda four-stroke power units and built-in shock absorption parts.
1. High-pressure speed, high efficiency.
2. Low center of gravity, stable and effortless operation.
3. Four-stroke Honda engine, with outstanding durability.
4. Internal combustion with low fuel consumption and noise.
Send Inquiry
Description



Crews use this ground compacting tool to repair driveways and parking lots. It carries an auto spray water set and large water storage tank to support hours of non-stop ground pressing. This Vibrating Compactor Plate avoids frequent water refills and stops asphalt sticking to the base plate.



Features



1.Honda four-stroke gasoline motors power this plate compactor, consuming less fuel and making soft running noise on outdoor job sites.
2.The machine's low center of gravity keeps steady contact with the ground while compacting. Staff hold the handle with less force and feel less soreness after long shifts.
3.Shock absorbing assemblies block most vibration from transferring to hand grips and ease long-hour manual work.
4.A big water tank with wide filler cap speeds up refilling; crews can tap any water supply available at construction yards.
5.Sprayers run while the plate presses ground, clearing stuck asphalt off the base all the time and leaving smooth unmarked pavement surfaces.
6.For large-area ground compaction projects, construction contractors always keep this Vibrating Compactor Plate as standard site gear.



Main Technical Parameters



GASOLINE PLATE COMPACTOR ZBR75S

WEIGHT

75KG

EXCITING FORCE

13KN

DIMENSION

700*400*910MM

DIMENSION OF TAMPING PLATE

560*400MM

VINRATION FREQUENCY

43RPM

OPERATION SPEED

14-18M/MIN

ENGINE MODEL

HONDA GX160/KOHLER CH260

HORSE POWER

6HP

WATER TANK VOLUME

7.5L

CERTIFICATION

2006/42/EC - 2006/95/EC / ISO 9001:2008
